Cat.No.
8030351112
Work plate Dimension
Ø134mm
Work plate material
Aluminum with ceramic coating
Max. stirring quantity [H2O]
3LX6
Speed range
200-1500rpm
Speed display
LCD
Temperature display
LCD
Heating temperature range
25-280℃
Temperature control accuracy
±1℃(<100℃)， ±1%(>100℃)
Temperature display accuracy
0.1℃
External temperature sensor
PT1000（accuracy±0.2℃）
"Hot" warning
50℃
Overheating protection
420℃
Motor type
Brushless DC motor
Stirring positions
6
Max. magnetic bar length
40mm
Timer function
-
Protection class
IP21
Motor rating output
-
Power
605WX6
Heating output
600WX6
Voltage,Frequency
200-240V，50Hz
Dimension [WxDxH]
564X523X127mm
Weight
12.7Kg
Ambient temperature
5-40℃
Permissible ambient humidity
80% RH
Data connector
-
Motor rating input
-
